GTIN Code 0843173124070
GTIN Code 0843173124070
Elo 1902L 48.3 cm (19-) LCD Touchscreen Monitor - 5:4 - 14 ms Typical
ET1902L-2UWA-0-BL-NS-G HDMI PCAP
Technical infomations
| Aspect Ratio | 5:4 |
| Backlight Technology | LED |
| Brand Name | Elo |
| Brightness | 250 cd/m² |
| Built-in Devices | USB Hub |
| Colour Supported | 16.7 Million Colours |
| Depth with Stand | 193.40 mm |
| Depth | 41.6 mm |
| Environmental Certification | China RoHS |
| Environmental Certification | REACH |
| Environmental Certification | WEEE |
| Features | Digital Signage Ready |
| Features | Multi Language Display |
| Features | On-screen Display (OSD) |
| Features | OSD/Power Lock |
| Features | VividPixel Technology |
| Features | Wide Viewing Angle |
| Frequency | 50 Hz |
| Frequency | 60 Hz |
| HDMI | Yes |
| Height with Stand | 397.70 mm |
| Height | 354.6 mm |
| Horizontal Frequency | 30 kHz to 82 kHz |
| Horizontal Viewing Angle | 178° |
| Limited Warranty | 3 Year |
| Manufacturer Part Number | E125695 |
| Manufacturer Website Address | http://www.elotouch.com |
| Manufacturer | Elo Touch Solutions, Inc |
| Marketing Information | 1902L Touchscreen Monitor The Elo 02-Series of Touchscreen Monitors designed with seamless style across all sizes includes four options a 19-inch square aspect ratio display and 22, 24 and 27-inch wide aspect ratio displays. With a compact form factor and clean design for easy integration, the 02-Series monitors are well-suited for point-of-sale, point of information, signage and hospitality applications. And with a variety of peripherals, the monitors can be transformed to meet the demands of your blueprint. Brilliant Displays from 19 to 27-inches The brilliant touchscreens with Elo's industry-leading TouchPro® PCAP technology offer wide viewing angles with impeccable image clarity, resolution, and light transmission for accurate touch response and vivid images. With up to 10 touches enabled, the 02-Series Monitors, provide a tablet-like experience. Well-Suited for... Not all businesses have the same needs. Whether you need a touchscreen at the point of sale to process a transaction or in a restaurant to enable self-service for guests to view your menu and submit their order, the line of 02-Series monitors can support the installation needs with ease while maintaining a modern, sleek aesthetic. Elo Edge Connect™ Lets You do More! Built with versatility in mind, the Elo Edge Connect system offers a wide assortment of peripheral options. Whether for endless aisle, self-order or collaboration applications, you can seamlessly attach any combination of up to four peripherals to the edge of the touchscreen creating a bespoke solution. And, you can add or move them later as your needs change! Fingerprint Scanner The Biometric Fingerprint Scanner can be attached to provide secure and quick login. MSR Elo offers the flexibility of integrating payment devices, including a Magtek 3-track encryptable MSR payment terminal. Barcode Scanner Enhance self-service checkout and price-checker applications by coupling a high-performance barcode scanner onto the Elo touchscreen. NFC The Near Field Communication (NFC) adapter can be integrated for easy mobile payments with just a touch of the phone. One for You. One for Your Customers. Offer your customers a point of interaction by adding a touchscreen for them to review their transactions, participate in loyalty programs or see the latest promotion. Mount with Flexibility Customers demand a seamless shopping experience from first step into the store through check-out. From the stands that come with the monitors to pole mounts, shelf mounts, wall mounts and 3rd party VESA mounts, the touchscreens can be integrated with ease. Built-to-Last The 02-Series Touchscreen Monitors deliver the quality and reliability Elo is known for and are backed by our 3-year standard warranty with an optional extension to 5-years. We design, build and are responsible for the complete solution,with touch integrated from the start. |
| Maximum Resolution | 1280 x 1024 |
| Mount Type | Pole Mount |
| Mount Type | Shelf Mount |
| Mount Type | Wall Mountable |
| Multi-touch Screen | Yes |
| Native Contrast Ratio | 1,000:1 |
| Near Field Communication (NFC) | Yes |
| Number of Simultaneous Touchpoints | 10 |
| Package Contents |
|
| Packaged Quantity | 1 |
| Panel Technology | Thin Film Transistor (TFT) |
| Placement | Tabletop |
| Product Color | Black |
| Product Family | 02 |
| Product Model | 1902L |
| Product Name | 1902L 19- Touchscreen Monitor |
| Product Series | 02 |
| Product Type | LCD Touchscreen Monitor |
| Response Time | 14 ms Typical |
| Screen Mode | SXGA |
| Screen Size Class | 482.60 mm |
| Speakers | Yes |
| Touchscreen Type | Projected Capacitive |
| USB | Yes |
| Vertical Frequency | 50 Hz to 75 Hz |
| Vertical Viewing Angle | 178° |
| VESA Mount Compatible | Yes |
| VESA Mount Standard | 100 x 100 |
| VGA | Yes |
| Viewable Screen Size | 48.3 cm (19-) |
| Weight (Approximate) | 4.30 kg |
| Weight with Stand (Approximate) | 6.30 kg |
| Width with Stand | 429.60 mm |
| Width | 429.6 mm |
