APC by Schneider Electric Smart-UPS On-Line Double Conversion Online UPS - 10 kVA/10 kW
IN

Technical infomations
Backup/Run Time (Full Load) | 3 Minute |
Backup/Run Time (Half Load) | 12 Minute |
Battery Characteristics | Maintenance-free, Sealed, Spill-proof |
Battery Chemistry | Lead Acid |
Brand Name | APC by Schneider Electric |
Bypass Switch | Automatic & Manual |
Certifications & Standards |
|
Depth | 715 mm |
Emergency Power OFF | Yes |
Environmental Certification | REACH |
Environmental Certification | RoHS |
Environmentally Friendly | Yes |
Form Factor | Tower |
Height | 432 mm |
Input Voltage | 230 V AC |
Limited Warranty | 3 Year |
Load Capacity (VA) | 10 kVA |
Load Capacity (W) | 10 kW |
Load Capacity | 10 kVA/10 kW |
Manufacturer Part Number | SRT10KXLI |
Manufacturer Website Address | http://www.schneider-electric.com |
Manufacturer | Schneider Electric SA |
Marketing Information | A versatile UPS developed for the harshest power conditions in the world. |
Maximum Operating Temperature | 40°C |
Network (RJ-45) | Yes |
Number of Batteries | 2 |
Output Voltage | 230 V AC |
Package Contents |
|
Plug/Connector Type | Hard Wire 3 wire (1PH+N+G) |
Plug/Connector Type | Hard Wire 5-wire (3PH + N + G) |
Product Color | Black |
Product Family | Smart-UPS On-Line |
Product Line | Smart-UPS On-Line |
Product Name | Smart-UPS SRT 10000VA 230V |
Product Type | Double Conversion Online UPS |
Protection Type | Surge |
Receptacle Detail | 1 x Hard Wire 3-wire (H N + G) |
Receptacle Detail | 4 x IEC 60320 C19 |
Receptacle Detail | 6 x IEC 60320 C13 |
Receptacle Type | Hard Wire 3-wire (H N + G) |
Receptacle Type | IEC 60320 C13 |
Receptacle Type | IEC 60320 C19 |
Sound Emission (A-Weighted) | 55 dB(A) |
Surge Energy Rating | 480 J |
Thermal Dissipation | 2002 BTU/h |
Total Number of Expansion Slots | 1 |
Typical Battery Recharge Time | 1.50 Hour |
USB | Yes |
Waveform Type | Sine Wave |
Weight (Approximate) | 111.82 kg |
Width | 263 mm |
