APC by Schneider Electric Smart-UPS Double Conversion Online UPS - 1.50 kVA/1.50 kW
APC SMART-UPS SRT 1500VA RM - ONDULEUR (RACK-MONTABLE) - CA 230 V - 1500 WATT - 1500 VA - ETHERNET 10/100, USB, SERIAL - CONNECTEURS DE SORTIE : 6 - PFC - 2U - NOIR - AVEC APC UPS NETWORK MANAGEMENT CARD AP9631
Technical infomations
| Application/Usage | Computer |
| Application/Usage | Industry |
| Application/Usage | IT Equipment |
| Application/Usage | Network |
| Application/Usage | Server |
| Backup/Run Time (Full Load) | 5.20 Minute |
| Backup/Run Time (Half Load) | 14.20 Minute |
| Battery Characteristics | Maintenance-free, Sealed, Leak-proof |
| Battery Chemistry | Lead Acid |
| Battery Size | 48V |
| Brand Name | APC by Schneider Electric |
| DC System Voltage | 48 V DC |
| Depth | 505 mm |
| Environmentally Friendly | Yes |
| EPO Port | Yes |
| Form Factor | Tower/Rack Convertible |
| Height | 85 mm |
| Hot Swappable | Yes |
| Input Frequency | 70 Hz |
| Input Voltage | 230 V AC |
| Load Capacity (VA) | 1.50 kVA |
| Load Capacity (W) | 1.50 kW |
| Load Capacity | 1.50 kVA/1.50 kW |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Manufacturer | Schneider Electric SA |
| Marketing Information | Smart-UPS On-Line High density, double-conversion on-line power protection with scalable runtime Smart-UPS On-Line provides high density, true double-conversion on-line power protection for servers, voice / data networks, medical labs, and light industrial applications. Capable of supporting loads from 1 to 20kVA in a rack/tower convertible form, the Smart-UPS On-Line is available from 2U to 12U. Recent family extensions at 15 and 20kVA enable support of power hungry blade servers or heavily loaded equipment racks. When business-critical systems require runtime in hours, not minutes, Smart-UPS On-Line can be configured with matching battery packs to comply with aggressive runtime demands. The included PowerChute management software provides unattended graceful shutdown of network operating systems. All models 5kVA and above include an integrated Network Management Card for remote management (optional on models below 5 kVA). The Smart-UPS On-Line family provides customers with a reliable source of uninterruptible power even in demanding power environments, including very wide input voltage window, extremely tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction. |
| Maximum Operating Elevation | 3 km |
| Maximum Operating Temperature | 40°C |
| Maximum Storage Elevation | 15 km |
| Network (RJ-45) | Yes |
| Number of Batteries | 1 |
| Operating Humidity | 0% - 95% |
| Output Frequency | 60 Hz |
| Output Voltage | 220 V AC |
| Output Voltage | 230 V AC |
| Output Voltage | 240 V AC |
| Overload Protection | Yes |
| Plug/Connector Type | British BS1363A |
| Plug/Connector Type | IEC 60320 C14 |
| Plug/Connector Type | SCHUKO CEE 7 EU1-16P |
| Product Family | Smart-UPS |
| Product Line | Smart-UPS |
| Product Name | Smart-UPS 1.5KVA Tower/Rack Convertible UPS |
| Product Type | Double Conversion Online UPS |
| Rack Height | 2U |
| Receptacle Detail | 6 x IEC 60320 C13 |
| Receptacle Type | IEC 60320 C13 |
| Replaceable Battery | Yes |
| Serial Port | Yes |
| Software Included | APC PowerChute Network Shutdown Software |
| Sound Emission (A-Weighted) | 50 dB(A) |
| Status Indicators |
|
| Storage Relative Humidity | 0% - 95% |
| Storage Temperature | -20°C - 50°C |
| Surge Energy Rating | 432 J |
| Thermal Dissipation | 317 BTU/h |
| Transfer Time | 0 ns |
| Typical Battery Recharge Time | 3 Hour |
| USB (HID Compliant) Port | Yes |
| Waveform Type | Pure Sine Wave |
| Weight (Approximate) | 21 kg |
| Width | 432 mm |
