QNAP TS-431P3-2G 4 x Total Bays SAN/NAS Storage System - 512 MB Flash Memory Capacity - Annapurna Labs Alpine AL-314 Quad-core (4 Core) 1.70 GHz - 2 GB RAM - DDR3 SDRAM Tower
Technical infomations
Brand Name | QNAP |
Controller Type | Serial ATA/600 |
Depth | 219 mm |
Ethernet Technology | 2.5 Gigabit Ethernet |
Flash Memory Capacity | 512 MB |
Form Factor | Tower |
Height | 169 mm |
Manufacturer Website Address | http://www.qnap.com |
Manufacturer | QNAP Systems |
Marketing Information | Powered by Annapurna Labs Alpine AL-314, quad-core 1.7 GHz processor, 2GB DDR3L RAM, one 1GbE LAN port and one 2.5GbE LAN port, the TS-431P3 features a 2.5GbE RJ45 port, providing up to 2.5 times the speed of regular Gigabit Ethernet and enabling smoother multimedia playback and everyday usage. The TS-431P3 ensures data security by supporting AES 256-bit encryption and various local/remote/cloud backup options - including snapshot protection that allows for files and data to be reverted to previously-recorded states if they are accidentally deleted, modified or affected by malware.
Build a faster home network with QNAP The TS-431P3 includes a 1GbE port and a 2.5GbE port to provide a smoother NAS experience and multimedia playback. Additional network connection options from QNAP include USB 3.2 Gen 1 to 5GbE adapters (supports N-BASET/Multi-Gig), QXG 5GbE PCIe cards, and QNAP QSW 10GbE switches. All these options allow users to revolutionize their home network at a cost-effective price. The TS-431P3 features three USB 3.2 Gen 1 port that delivers outstanding multitasking performance. Easy and Secure File Management File Station allows direct management of files stored on the TS-431P3 and in the cloud. Users can easily upload files from their PC, drag/drop files between folders, rename/delete files, and configure file/folder permissions to prevent unauthorized access. Users can also use Microsoft Office Online to directly view/edit Microsoft Office documents stored on the TS-431P3. Confidential/sensitive data can also be encrypted to add extra security. Multi-Point File Backup, Access, and Sync The TS-431P3 supports file sharing protocols (including SMB/CIFS, AFP and NFS) for Windows®, Mac®, and Linux®/UNIX® devices. Coupled with Qsync (a utility that transforms a QNAP NAS into a secure, high-capacity data center for file synchronization) any file uploaded to the TS-431P3 becomes available for all linked devices (such as computers, laptops, and mobile devices). Hybrid Backup Sync helps backup/synchronize data on the TS-431P3 to another QNAP NAS, remote server, or cloud storage for disaster recovery. Additionally, QuDedup technology greatly improves the efficiency of multi-version backup to destination storage, while optimizing storage utilization. You can install the QuDedup Extract Tool on your computer and restore deduplicated files to their normal status. |
Maximum Power Supply Wattage | 90 W |
Memory Technology | DDR3 SDRAM |
Network (RJ-45) | Yes |
Number of 2.5-/3.5- Bays | 4 |
Number of Hard Drives Installed | 0 |
Number of Hard Drives Supported | 4 |
Number of Network (RJ-45) Ports | 2 |
Number of Solid State Drive Installed | 0 |
Number of Solid State Drive Supported | 4 |
Number of Total Expansion Bays | 4 |
Number of USB 3.2 Gen 1 Ports | 3 |
Operating System | QTS 4.4.2 |
Processor Core | Quad-core (4 Core) |
Processor Manufacturer | Annapurna Labs |
Processor Model | AL-314 |
Processor Speed | 1.70 GHz |
Processor Type | Alpine |
Product Model | TS-431P3-2G |
Product Name | Quad-core 1.7GHz NAS with 2.5GbE and Feature-rich Applications for Home & Office |
Product Type | SAN/NAS Storage System |
Protocols | AFP |
Protocols | CIFS/SMB |
Protocols | DDNS |
Protocols | DHCP |
Protocols | FTP |
Protocols | FXP |
Protocols | HTTP |
Protocols | HTTPS |
Protocols | IPSec |
Protocols | IPv4 |
Protocols | IPv6 |
Protocols | iSCSI |
Protocols | L2TP |
Protocols | NAT |
Protocols | NFSv3 |
Protocols | NFSv4 |
Protocols | PPTP |
Protocols | SFTP |
Protocols | SMTP |
Protocols | SNMPv2 |
Protocols | SNMPv3 |
Protocols | SSH |
Protocols | SSL/TLS |
Protocols | SSL |
Protocols | STP |
Protocols | TCP/IP |
Protocols | TFTP |
Protocols | TLS |
Protocols | UPnP |
Protocols | WEBDAV |
RAID Levels | 0, 1, Hot Spare, JBOD |
RAID Supported | Yes |
Standard Memory | 2 GB |
Total Number of USB Ports | 3 |
Weight (Approximate) | 2.01 kg |
Width | 160 mm |
